General Product Overview
| Attribute | Detail |
| Product Type | Interactive Flat Panel |
| Model Identification | IS-6518 (3576.B) |
| Ecosystem Certification | Google EDLA |
| Core Display Capability | 4K Ultra HD display (supports full channel 4K UI display) |
Display Panel Specifications
| Feature | Specification |
| LCD Size | 65” |
| Type of Panel | IPS / VA |
| Visual Ratio (Aspect Ratio) | 16:9 |
| Max Visual Area | 1428.48 (H) × 803.52 (V) mm |
| Resolution | 3840 (H) × 2160 (V) |
| Pixel Pitch | 0.372 × 0.372 mm |
| Frequency (Refresh Rate) | 60Hz |
| Display Colors | 1.07B (10bit) |
| Color Saturability | 72% |
| Contrast Ratio (Typ) | 4000:1 |
| Viewing Angle | 178° (H/V) |
| Light Source | DLED |
| Brightness | 400 cd/m² |
| Life Span | ≥ 60,000 hours |
| Bonding Technology | Zero gap Bonding technology (low parallax writing and wider viewing angles) |
| Glass Quality | 4mm anti-glare toughened glass with high haze OC for clearer display against ambient light interference |
| Dimming & Comfort | Light-sensitive brightness adjustment and DC dimming support (de-flashing) for an eye-protection display |
Touch & Interaction Parameters
| Feature | Specification |
| Touch Specifications | Non-contact infrared sensing technology |
| Touch Points | 20 Points Touch |
| Touch Accuracy / Depth | ±1mm (High precision infrared touch control for smooth writing) |
| Minimum Identifier | 2mm |
| Input Mode | Opaque object (finger, pen, etc.) |
| Response Time | ≤ 6ms |
| Writing Height | ≤ 3mm |
| Writing Display | Single Stylus pen two-colour (supports dual pens and dual colour displays for multi-person collaboration) |
| Output Coordinates | 32767 (W) × 32767 (D) |
| Support Systems | Windows 10 / Windows 8 / Windows 7 / Windows XP / Android / Linux / Mac OS X / Chrome |
Audio-Video Parameters
| Component | Configuration |
| Soundtrack Layout | 2.2 |
| Speaker Power | 2 × 20W |
| Woofer | 20W (Optional) |
System & Processing Architecture
| Component | Configuration |
| System Version | Android 14.0 |
| CPU | Quad-core Cortex A72 × 4 + Quad-core Cortex A53 × 4 |
| GPU | G52 MC3 |
| RAM | 8GB (Standard) / 16GB (Optional) |
| ROM | 128GB (Standard) / 256GB (Optional) / 512GB (Optional) |
Modular OPS PC Expansion
| Component | Configuration |
| System Version | Windows 11 Pro |
| CPU | Intel® Core™ i3 / i5 / i7 processor (12th / 13th / 14th Gen) |
| RAM | 8GB / 16GB / 32GB |
| Storage | 128GB / 256GB / 512GB / 1 TB NVMe / 1TB HDD |
Connectivity & Intelligent Features
| Category | Supported Features / Interface Ports |
| Front Interface Ports | Front Type C × 1 + USB 3.0 × 2 + HDMI IN × 1 + Touch USB × 1 (supports switching with channels) |
| Network & Wireless | Wi-Fi 6, dual-band 2.4G/5G, AP+STA operating mode |
| Network Sharing | One network support, Android and OPS both on Gigabit network (supports network sharing) |
| Projection Support | Support for Wireless projection |
| Productivity Tools | Split screen, parallel tasks, wider scenes, eye protection, lock screen, touch lock |
| AI Features | AI Pen, Circle scan, Audio Translate, AI Q&A, Video recap, etc. |
